Advertising gate in daily use may encounter some common problems, the following is the summary of these problems and the corresponding solution:

After the power is turned on, press the switch off or switch off key, the railing does not move:

Possible causes:

The fuse of the advertising channel brake is blown.

There is no battery in the remote control or the battery power is insufficient.

Same frequency interference near the advertising gate.

The external protection circuit is faulty or in the protection state.

Advertising channel gate control table short circuit.

Advertising gate encoder short circuit.

The power supply of the gate switch is damaged.

Advertising gate infrared device short circuit.

Elimination method:

Check the fuse and power supply in the main control box.

Check the battery in the remote control.

Check the infrared and ground sensing coils respectively.

OPEN the gate door and press and hold the Open or CLOSE key of the main controller.

Check the gate control table.

Check the advertising channel gate encoder.

Replace the switch power supply of the advertising gate.

Check the advertising gate infrared device.

The motor works and the rail cannot take off and land:

Possible causes:

It is difficult to start when the gate railing is in the middle position.

Balance gate spring tension is not properly adjusted.

The gate voltage is insufficient.

Advertising gate motor line short circuit.

Elimination method:

Turn off the power supply of the advertising channel gate, connect the hand device with the hand rocker, turn the railing of the advertising channel gate to the horizontal or vertical position, and then turn on the power supply of the advertising channel gate to start the machine.

Adjust the gate spring screw to balance the spring with the railings.

Measure whether the gate voltage is in the range of 220 V±10 V.

Check the advertising gate line.

Railing page turn does not open or close:

Possible causes:

Advertising gate railing page damage, resulting in unable to turn.

The motor that starts the page turning is broken, so that the page turning can not be closed.

Mistakenly press the fourth key of the remote control of the advertising channel gate, so that the page will not be closed, and the rack that drives the page is damaged.

Elimination method:

Inspect and replace damaged pages.

Replace the gate motor.

Click the fourth button of the remote control again.

Replace damaged gate rack.

Other frequently asked questions:

The loose screw of the gate is loose: the upper and lower positions are not accurate. The maintenance method is to use an 80mm long iron rod with a diameter of 4 to Pierce the two-headed screw and rotate between them to adjust the brake rod up and down in place.

Power off protection switch power off: When the control of the advertising gate fails, the total power is disconnected and the machine does not work. The repair method is to open the door of the machine, and the large belt can be restored when it is rotated 3-8 turns clockwise to the upper.

Loose coil buried wire: When the local sensing coil is not strongly fixed in the nest, the sensation of the car pressing across the road will constitute the deformation of the coil in the nest. The repair method is to pour melted asphalt into it to hold it in place.

In order to ensure the normal operation of the advertising gate and extend the service life of the equipment, the following points need to be noted:

Regular inspection: regular inspection of all parts of the gate, including motor, mechanical transmission system, control system, etc. If any exception is found, handle it in time to keep the device in good condition.

Cleaning and maintenance: Regular cleaning of advertising gate, including chassis, gate rod, advertising light box and other components. Use a clean, damp cloth to wipe dust and dirt off the surface and make sure the advertising content is clearly visible.

Lightning protection and waterproof: For outdoor sluice gates, take lightning protection and waterproof measures to prevent damage caused by lightning strikes and water flooding.

Pay attention to safety: When operating the gate, pay attention to traffic safety to prevent vehicles and pedestrians from being hurt during the operation of the gate. Emergency measures shall be taken in time to ensure the safety of equipment and personnel in case of gate failure or abnormality.

Please note that the above content is for reference only, for the maintenance and repair of advertising gate, it is recommended to contact professional equipment maintenance personnel for processing.
